BTBLMBSMINI

BTBLMBSMINI

This article will include setting up your keyboard and troubleshooting.

Quick Q & A:



Q: What type of devices can I connect this keyboard to?

A:  Any Apple device including iPhone and iPad, as well as any non-Apple product.



Q: How do I know if the battery is low?

A: The green LED light will flash.



Q: How do I know when the keyboard is done charging?

A: The green LED light in the corner will turn off.



Q: How long does it take to fully charge?

A: 3-5 hours



Q: How long will my keyboard last after a full charge?

A: Backlight on all the time - approximately 2 weeks. No usage of the backlight - approximately 3 months.



Q: Why does my backlight turn off after a few seconds of non-use?

A: This keyboard comes with a battery saver that automatically turns the backlight off after inactivity.



How to set up my keyboard

  • Turn keyboard on.
  • Press and hold Fn + 1 at the same time for 3-5 seconds (you should see a rapid blinking green light).
  • Go to Settings > Bluetooth > BTBLMBSMINI should pop up under Nearby Devices > Press Connect



For Apple users only - Keyboard set-up assistant

Once you have successfully connected your keyboard to your Mac, you may get a pop-up that states you  need to identify your keyboard (Keyboard Set up Assistant). Here are the steps:

  1. Click on continue
  2. Press and release the 'Z' key
  3. Press and release the '/?' key
  4. Choose 'ANSI' as your region
  5. Click 'Done'

Note: There are two instances when this pop up may not come up - The first being the connection was unsuccessful. You can check if this is the case by doing a quick test type in any application you'd like (i.e. Google, Safari, Notes), if you are not able to type, you may want to go through the sync instructions again. The second reason the pop up may not appear consistently is because it only triggers when a new, unknown USB or Bluetooth keyboard is detected, or if the system fails to recognize an existing one due to connectivity glitches. You can always manually do it by:

Settings > Keyboards > Change keyboard type  - (go through process listed above)



How to pair my keyboard with multiple devices

  • Once your keyboard has already been paired to One device (see instructions above), we can proceed to set up the other channels.
  • Turn keyboard on.
  • To set up Channel 2 (B2), press and hold Fn + 2 at the same time for 3-5 seconds (you should see a rapid blinking green light).
  • Go to Settings > Bluetooth > BTBLMBSMINI should pop up under Nearby Devices > Press Connect
  • To set up Channel 3 (B3), press and hold Fn + 3 at the same time for 3-5 seconds (you should see a rapid blinking green light).
  • Go to Settings > Bluetooth > BTBLMBSMINI should pop up under Nearby Devices > Press Connect



My keyboard isn't working

  • Check if it needs a charge.
  • If the battery gets too low, the keyboard may drop connect. You may have to remove/forget the device and re-connect the keyboard.
  • There could be a channel failure, you may need to change channels.
